HSD JR. • LEARN. FLY. GROW.
Big Jet Looks. Beginner-Friendly Flying.
The HSD Jr. Mini Parkflyer F-22 brings fighter-inspired styling to a lightweight EPP aircraft designed to make RC flying approachable. Compact, durable and quick to assemble, it combines brushless power with true servo-controlled flight surfaces for a more authentic flying experience than typical toy-grade aircraft.
Durable EPP Airframe Lightweight and impact-resistant construction built for learning.
Brushless Power 2204-2600KV brushless motor paired with a 20A brushless ESC.
Servo Control Two 9g servos provide positive control of the aircraft's flight surfaces.
Gyro Stabilization RTF configuration includes a gyro-equipped receiver to help smooth flight.
Designed for First Flights
The F-22 580 is designed for new and developing RC pilots who want something more engaging than a basic trainer. Its compact size makes it convenient to transport, while the lightweight EPP structure helps tolerate the bumps that naturally come with learning.
Unlike simple differential-thrust toy aircraft, the F-22 uses dedicated servos for aircraft control and a brushless power system for stronger, more consistent performance.
Quick Assembly
The main airframe is largely integrated from the factory. Final assembly is designed to be simple, with HSD listing approximately five minutes of assembly time for the RTF configuration. That means less time at the workbench and more time learning to fly.
Specifications
| Wingspan | 580 mm / 22.83 in |
|---|
| Length | 817 mm / 32.16 in |
|---|
| Flying Weight | Approx. 350 g / 12.34 oz (RTF) |
|---|
| Airframe Material | EPP foam |
|---|
| Motor | 2204-2600KV brushless |
|---|
| ESC | 20A brushless |
|---|
| Servos | 2 × 9g |
|---|
| Propeller | 6045 / 6 × 4.5 in, 2-blade |
|---|
| RTF Battery | 2S 7.4V 1200mAh 25C LiPo |
|---|
| RTF Radio | 2.4GHz 4-channel transmitter and gyro-equipped receiver |
|---|
| Approx. Flight Time | 10–15 minutes |
|---|
| Approx. Cruising Speed | 50 km/h / 31 mph |
|---|
| Published Control Distance | Up to 500 m |
|---|
| Takeoff Options | Ground slide or hand launch |
|---|
| Assembly Time | Approx. 5 minutes (RTF) |
|---|
| Recommended Experience | Beginner |
|---|
| Recommended Age | 14+ |
|---|
Choose Your Configuration
RTF — Ready to Fly
Aircraft with brushless motor, ESC and servos installed, plus 4-channel transmitter, gyro-equipped receiver, 2S 1200mAh LiPo battery and B3 charger.
PNP — Plug-N-Play
Aircraft with brushless motor, 20A ESC and two 9g servos installed. Requires compatible transmitter, receiver, 2S battery and charger.
KIT — Airframe
Airframe for pilots who want to choose their own motor, ESC, servos, radio system, battery and supporting electronics.
Color Options
The original F-22 580 lineup was offered in both Red and Blue. Availability may vary by configuration.
Important Safety Information This is a radio-controlled aircraft, not a conventional toy. HSD specifies operation for ages 14 and older. Fly only in an appropriate RC flying area, maintain safe separation from people and property, and follow the aircraft, radio and LiPo battery instructions before operation.
